CRDTs #3: Do Not Read!

Ever used a CRDT, thought you were safe, and—boom—you bought a Ferrari you didn't mean to? It could happen to you!

The truth is that CRDTs are dangerous to observe: they guarantee eventual consistency, but you'll never know when "eventual" arrives. That gap between what CRDTs promise and what you can safely read is generally not well protected in CRDT libraries, and it's exactly where the bugs sneak in. It is not safe to read a CRDT's raw state, people!

What CRDTs can offer—when used properly!—is monotonicity: the guarantee that once you've seen a fact, no future update will contradict it. And that's a powerful basis for providing safe APIs to your CRDTs.

This is the 3rd post in a series I'm doing on CRDTs. This one is particularly for you software engineers out there. News you can use.

Takeaways

Prologue: ‟Eventual Consistency”

Have you ever asked that age-old question, "Are we there yet?" Eventual consistency promises you'll eventually get to an agreed-upon value across replicas... but when is "eventual"? Tomorrow? Next year? After you've bought a Ferrari you didn't mean to?

Werner Vogels defined eventual consistency like this:

If no new updates are made to the object, eventually all accesses will return the last updated value.

Sounds reassuring, right? And it avoids expensive coordination protocols like Paxos or Two-Phase Commit.

But here's the catch: How do you know there are no new updates? In distributed systems, termination detection (i.e. "am I done yet?") requires knowing:

1. No node will issue any new messages.
2. No messages are in flight.

In logic, that's:

"there does not exist an $n$ where property $p(n)$ holds".

Any time you see a $\neg\exists$ (or its doppelganger, $\forall$) in distributed logic, beware! One rogue message — a single counter-example — can arrive at any time to invalidate the property.

👉 Termination ("eventuality") is non-monotonic. It can be true over a certain set of information, but become false if more data arrives.

The CALM Theorem says that eventual consistency without coordination is possible if and only if the program specification is monotonic. Thus (via CALM):

👉 Termination Detection requires Coordination.

So ... in coordination-free systems, you can never know when "eventual" has arrived!

🙋🏾‍♂️ Is Anything Safe Before ‟Eventual" comes?

This is a common misunderstanding. It's easy to confuse the formal guarantees of merge (which CRDTs provide) with the safety of reads (which they absolutely do not).

If you previously missed this, you are in good company. The danger of read is not prominent in online discussion, software packages, or the CRDT literature. Perhaps this post can serve as a warning and a pointer to more subtle discussion in the literature.

Let's illustrate the problem—and ways to use CRDTs responsibly.

🚨 Two-Phase Sets: Poster Child of the Problem

A 2-Phase (Add/Remove) Set CRDT maintains two sets:

struct 2PSet {
    adds: Set<(id, element)>;
    removes: Set<(id, element)>;
}

Merges? Safe—just union both sets.

fn merge(a: &2PSet, b: &2PSet) -> 2PSet {
  2PSet {
    adds: a.adds.union(&b.adds),
    removes: a.removes.union(&b.removes),
  }
}

But the read?

fn read(s: &2PSet) -> Set<element> {
  s.adds - s.removes
}

This read is non-monotonic: as removes grows, your read result shrinks. That's the trap.

So what could go wrong?

🥔 🏎️ The Potato/Ferrari Example

Here's an example of what could go wrong, from our Keep CALM and CRDT On paper:

While shopping online at RetailCo, you add a potato and a Ferrari to your cart. Reflecting on your finances, you decide to remove the Ferrari, and check out.

cart.add("potato");
cart.add("Ferrari");
cart.remove("Ferrari");
cart.checkout();

The CRDT-based cart is replicated, and unfortunately replica B receives checkout before remove. It reads the cart, and ships you a Ferrari. Boom.

👉 Merges are safe; reads are not. 2P-Sets? Nearly useless for safe reads.

What about Simpler CRDTs?

You might be saying:

Well, 2P-sets use a set difference operator, which is clearly non-monotonic. The CALM Theorem warned us that non-monotonic operations require coordination for consistency! But surely a plain old grow-only set is safe to read? After all, its read function looks nice and monotonic!

You'd be right that the read is monotonic:

read(s: GrowOnlySet) -> Set {
  s.adds
}
...
let c = GrowOnlySet.new();

And that seems safe locally. But wait until you see the downstream logic:

let ingredients = c.read();
if edible(&ingredients) {
  cook(&ingredients);
} else {
  panic!("InedibleError");
}

Both replicas start out empty—I think we can all agree that the empty set is inedible. But imagine replica A merges some yummy stuff:

c.merge(['apples', 'honey']);

We transition from !edible to edible.

Now suppose replica B merges some more stuff:

c.merge({'bleach', 'Paxos'})

Bleach and Paxos both have their uses, but please dont ingest them! Merging in more stuff transitions replica A back from edible to !edible. Even though c grows monotonically, edible is not a monotone function over c, so the result of edible(c) toggles from false to true to false at node A!

👉 The general point: even monotonic reads can lead to non-monotonic conclusions in downstream code.

This seems like pretty bad news! But all is not lost. Let's look at some ways to work with CRDTs that provides some guard rails.

🦺 Safety First: Encapsulate CRDT State

To prevent the kinds of surprises we just saw, CRDT state should be encapsulated, using a language that supports strong typing. If read is offered, it should be marked as unsafe.

A compiler might allow read without unsafe if it can prove all downstream logic is monotonic. But that's rare. Monotonicity is undecidable in general.

If you're in Rust, check out Hydro: we're working on these issues!

👍 Safe, Practical CRDT Usage: Lower Bounds and Threshold Functions

Are there any functions that can safely examine CRDT state? Yes indeed! Monotonicity to the rescue.

Specificaly, since the value of a properly-written CRDT should only go up over time, CRDTs give you trustworthy lower bounds. Just don't treat a lower bound as a final answer—a lower bound is a special type, which you can only compare using <=! In particular, you can't test for equality (==) with a lower bound.

In addition, you can expose monotone functions on CRDTs to safely compute on their evolving state. Let's see how.

✅ Thresholds: Coordination-Free Termination

Some lattices are bounded, which means they have a unique top element ($\top$). Once you hit $\top$, you're done! As a classic example, consider the boolean lattice with values {false , true} and merge function that computes $\vee$ (logical or).

Threshold functions are boolean functions (i.e. truth predicates) on lattices that exploit this:

• They map from a big (or unbounded) lattice to the boolean lattice
• They are monotone functions: as the input gets bigger, the output can never go down -- once true, always true!
• true is $\top$ and safe to read

Clearly edible is not a threshold function. What is a good example? Here are two examples on grow-only set lattices: once true, always true!

state.len() > 100;
state.contains('Apple Sauce');

CRDTs and threshold functions can be pretty useful. Even if your full lattice (like a set) has no practical $\top$, your threshold function does! Once you cross that threshold, you can treat the truth value as a stable boolean value—one that will be eventually consistent across nodes. So you can read the output of the threshold function safely.

Threshold functions are a common example, but you can safely use any monotone function that maps to any finite, ordered type! But remember: until your monotone function hits $\top$ in your output type, you're still in unsafe territory. Reads may still change! So threshold functions are only helpful when they become true $(\top)$.

🧭 So What Should Systems Do?

Realistically, many eventually consistent systems need to use some coordination at some point. And in many cases that's OK, especially if we can avoid coordination most of the time! As my colleague Natacha Crooks said once, "most programs are not monotonic, but most programs are mostly monotonic". So the trick is to put coordination in its place.

Here's some advice as you think about eventual consistency, CRDTs, monotonic programming, and the like:

1. Coordination is still needed to know when you're done.
Use it sparingly! For example, when you're pretty sure every node is done with a task or session — maybe because some coordination-free threshold has been met — you can employ a round of consensus to detect termination. (Of course if it fails you may have to wait and try again later.)

2. Don't trust CRDTs that have non-monotonic reads.
Non-monotonic read methods like that of 2P-sets are unsafe in any context: it doesn't matter what you do downstream, the read itself exposes you to non-monotonicity and hence race conditions. 2P-sets and their more complicated sibling, OR-sets, are quite troublesome in that respect. The only safe way to use them is to do coordination for each read—which probably makes 2P-sets no more efficient than your favorite transactional database!

3. Embrace strong typing and escape hatches. CRDT state should be encapsulated, and methods that expose the state should be marked unsafe. Even if the read is monotonic, downstream logic may not be. There are certainly cases where developers will want to take their non-deterministic chances reading the state of a CRDT, and that's their business! But for purposes of maintainability and code review, risky behavior of that sort should be explicitly flagged in code, just like Rust requires us to flag unsafe memory accesses.

4. Monotonic thresholds are your friend.
Thresholds and other monotone functions enable safe, observable progress without coordination — if you expect to hit $\top$.

In summary, I offer this:

CRDT Survival Guide

🧠 Want More?

If you're looking for formal research in this space that goes beyond the main CALM Theorem papers, check out these more recent results:

• Conor Power's recent theoretical work on Free Termination in ICDT 25 goes beyond thresholds to identify more cases where you can terminate without coordination.
• Be aware that researchers have found extensions to the CALM theorem, where global knowledge can allow coordination-free computation in more cases. The most recent paper in this line of work is from our friends Tim Baccaert and Bas Ketsman in a PODS 2023 paper.
• For original research on threshold functions, see Kuper and Newton's LVars.

...and stay tuned for the next post on CRDTs' algebraic properties.
